PE Pipe Price/HDPE PE Pipe Price/Competitive PE Pipe Price

    Payment Type: T/T,L/C
    Min. Order: 1000 Meter/Meters
    Delivery Time: 10 Days
    Packaging: standard export packaging or according to customers\' request.
    Brand: Zhongxing
    Place of Origin: Shandong, China (Mainland)
    Supply Ability: 20000 Meter/Meters per Month
  • Ms. Grace Xu

Product Description


Specifications



Plastic Pipes

1. Light weight

2. Corrosion resistance

3. Easy installation

4. High wear resistance















Our pipes are widely used in such fields as gas distribution, portable water and drainage water, dredging, transportation, environmental protection and chemical industr, etc.



Long service life: under rated temperature and pressure, the PE pipe can be used safety for more than 50 years.


Excellent resistance to corrosion capability: except few strong oxidants, it can endure the erosion of various kinds of chemical media, no electrochemical corrosion.


Excellent transportation capability: the inner side of the PE pipe is smooth and has litter abrasion and resistance. The absolute roughness k=1.01mm and [k" will not change with time.


Reliable joint capability: the intensity of the welded joint of Pe Pipes is above the pipe itself. The interface will not disconnect because of the moving of soil or the live load.


Reliable safety capability: PE pipe has strong capability of anti-cracking and is not prone to crack.


Better resistance to concussion capability: PE pipe possesses high toughness and can endure strong impact. Pressure of heavy things will not cause the pipe to break.


Strong toughness: PE pipe is a kind of pipe that possesses high toughness whose breaking elongation rate generally exceeds 500% and has strong ability to adapt to the uneven settlement of the pipe bending.


Excellent flexibility: PE pipe can be easy to change in accordance with the construction requirements. Small-diameter pipe is available to be supplied in coils.


Installation cost lower: light weight, easy handling and installing, simple welding technique and exemption of being embalmed result in low construction cost.






Size range:





Nominal outside diameter Wall thickness (mm)
SDR26 SDR21 SDR17 SDR13.6 SDR11
Nominal pressure (Mpa)
(inch) (mm) PN0.6 PN0.8 PN1.0 PN1.25 PN1.6
1.25 32 3.0
1.5 40 3.7
1.9 50 4.6
2.48 63 4.7 5.8
2.9 75 4.5 5.6 6.8
3.5 90 4.3 5.4 6.7 8.2
4.3 110 4.2 5.3 6.6 8.1 10.0
4.9 125 4.8 6.0 7.4 9.2 11.4
5.5 140 5.4 6.7 8.3 10.3 12.7
6.2 160 6.2 7.7 9.5 11.8 14.6
7.0 180 6.9 8.6 10.7 13.3 16.4
7.8 200 7.7 9.6 11.9 14.7 18.2
8.8 225 8.6 10.8 13.4 16.6 20.5
9.8 250 9.6 11.9 14.8 18.4 22.7
11.0 280 10.7 13.4 16.6 20.6 25.4
12.4 315 12.1 15.0 18.7 23.2 28.6
13.9 355 13.6 16.9 21.1 26.1 32.2
15.7 400 15.3 19.1 23.7 29.4 36.3
17.7 450 17.2 21.5 26.7 33.1 40.9
19.6 500 19.1 23.9 29.7 36.8 45.4
22 560 21.4 26.7 33.2 41.2 50.8
24.8 630 24.1 30.0 37.4 46.3 57.2
27.9 710 27.2 33.9 42.1 52.2
31.5 800 30.6 38.1 47.4 58.8





Nominal outside diameter Weight (kg/m)
SDR26 SDR21 SDR17 SDR13.6 SDR11
Nominal pressure (Mpa)
(inch) (mm) PN0.6 PN0.8 PN1.0 PN1.25 PN1.6
1.25 32 0.283
1.5 40 0.437
1.9 50 0.676
2.48 63 0.895 1.076
2.9 75 1.031 1.265 1.508
3.5 90 1.203 1.493 1.819 2.178
4.3 110 1.454 1.802 2.214 2.685 3.234
4.9 125 1.888 2.318 2.838 3.455 4.204
5.5 140 2.379 2.917 3.555 4.337 5.246
6.2 160 3.113 3.817 4.653 5.671 6.869
7.0 180 3.897 4.788 5.898 7.184 8.842
7.8 200 4.822 5.949 7.262 8.847 10.913
8.8 225 6.049 7.534 9.223 11.439 13.814
9.8 250 7.518 9.202 11.316 14.072 17.023
11.0 280 9.398 11.631 14.480 17.671 21.325
12.4 315 11.943 14.629 18.341 22.379 27.036
13.9 355 15.110 18.915 23.331 28.386 34.297
15.7 400 19.120 24.121 29.525 35.999 43.555
17.7 450 24.693 30.499 37.421 45.636 55.196
19.6 500 30.484 37.689 46.248 56.344 68.085
22 560 38.206 47.199 57.910 70.670 85.351
24.8 630 48.467 59.623 73.360 89.347 108.135
27.9 710 61.625 75.948 93.136 113.543
31.5 800 78.149 96.267 118.098 144.099


Contact us if you need more details on Hdpe Plastic Water Pipe. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Plastic Pipes for Water、Plastic Water Flume. If these products fail to match your need, please contact us and we would like to provide relevant information.

Product Categories : Plastic Pipes > PE Pipes
